Eurolite MD-3050 Safety Spiegelbolmotor – 150 cm max – 1 RPM
Oorspronkelijke prijs was: 236,81.173,55Huidige prijs is: 173,55.
Op voorraad voor 16:00 besteld maandag in huis.
Gratis verzending vanaf 100 euro.
Veilig bestellen en betalen via iDeal, Afterpay, Creditcard en Bancontact.
We adviseren je graag! Neem contact met ons op.
Keuze uit 3400 Afhaalpunten van PostNL
International shipping, whole of Europe.
Availability: Op Voorraad - Op werkdagen voor 22:00 besteld volgende dag in huis.
Artikelnummer: 50301540
- Beschrijving
- Extra informatie
- Beoordelingen (0)
Beschrijving
Beschrijving
Safety features
? Rugged construction with steel housing for long operation
? High stability due to massive motor axle
? Mechanic fall safety against axle loosening inside the motor
? Approved load with 12-fold testing weight
? Additional attechment eyelet for secondary attachment of the load
? EUROLITE safety rotary motors comply with the safety norm EN 292 and safety regulation BGV C1 (Germany)
? Quality management for testing every production charge
? Rugged construction with steel housing for long operation
? High stability due to massive motor axle
? Mechanic fall safety against axle loosening inside the motor
? Approved load with 12-fold testing weight
? Additional attechment eyelet for secondary attachment of the load
? EUROLITE safety rotary motors comply with the safety norm EN 292 and safety regulation BGV C1 (Germany)
? Quality management for testing every production charge
Mirror ball motor for mirror balls up to 150 cm
- Suitable for driving mirror balls up to a maximum weight of 150 kg
- This weight corresponds with a diameter of 150 cm for the EUROLITE mirror balls
- The maximum load always means the mirror ball weight including the mirror ball chain, the safety chain and the fixation material
- 2 chains and 4 quick links must be ordered separately
- 1 rotation per minute
- For professional use, e.g. in discotheques and in public places, the EN DIN 15560 norms have to be considered
- The motor always has to be installed with a secondary safety attachment
- Before taking into operation for the first time, the installation has to be approved by an expert
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | 7 W |
| Maximum load WLL (4-fold): | 450 kg |
| Maximum load BGV C1 (8-fold): | 225 kg |
| Maximum load BGV C1 (10-fold): | 180 kg |
| Maximum load BGV C1 (12-fold): | 150 kg |
| Max. diameter of mirror ball: | 150 cm (EUROLITE) |
| Rotation-speed: | approx. 1 RPM |
| Dimensions (L x W x H): | 280 x 240 x 110 mm |
| Weight: | 5 kg |
Extra informatie
Extra informatie
| Gewicht | 6 kg |
|---|---|
| Afmetingen | 0,2200 × 0,3000 × 0,2650 m |
| Maximum load kg | 150 |
| Weight kg | 5 |
| Power supply | 230 V AC, 50 Hz |
| Power consumption W | 7.00 |
